STRATTOS S7X
STRATTOS S7X 2026
-
N/A
Cheers to the riders who just cannot get enough! Our all-rounder whiz, Strattos S7D Carbon road bike is designed to accompany its rider on every ride – converting even the final stretch of the longest rides to be just as joyful as the start of any fresh new day. Get ready to hike new mountains and break your personal bests, because this road bike will make you perform your best for longer.
Specification
*Specifications, colors, and product availability are subject to change without prior notice.
-
Frameset
FramesetForkFrame ColorDecal Color
-
Drivetrain
ShifterCrankCassetteRear DerailleurChain
-
Cockpit
SaddleSeatpostHandlebarHandlestem
-
Wheel & Tire
Wheel SizeTireRimHub
-
Brake
Brake LeverBrake CaliperRotor
Geometry & Size
| XXS | XS | S | M | L | XL | XXL | |
|---|---|---|---|---|---|---|---|
| Height (cm) | 151-161 | 154-164 | 162-170 | 168-176 | 174-181 | 180-187 | 185-195 |
| Seat Tube Length (A) | 439.1 17.29 | 454.2 17.88 | 474.2 18.67 | 500 19.69 | 524.7 20.66 | 554.3 21.82 | 584.2 23 |
| Seat Tube Angle (B) | 75 2.95 | 75 2.95 | 74.5 2.93 | 74 2.91 | 73.5 2.89 | 73 2.87 | 73 2.87 |
| Effective Seat Tube Angle (C) | 75 2.95 | 75 2.95 | 74.5 2.93 | 74 2.91 | 73.5 2.89 | 73 2.87 | 73 2.87 |
| Head Tube Length (D) | 90 3.54 | 90 3.54 | 105 4.13 | 130 5.12 | 155 6.1 | 185 7.28 | 215 8.46 |
| Head Tube Angle (E) | 70.5 2.78 | 72 2.83 | 72.5 2.85 | 73 2.87 | 73 2.87 | 73 2.87 | 73 2.87 |
| Effective Top Tube (F) | 505 19.88 | 515 20.28 | 525 20.67 | 540 21.26 | 555 21.85 | 570 22.44 | 590 23.23 |
| Bb Height (G) | 271.5 10.69 | 271.5 10.69 | 271.5 10.69 | 274 10.79 | 274 10.79 | 276.5 10.89 | 276.5 10.89 |
| Bb Offset (H) | 72.5 2.85 | 72.5 2.85 | 72.5 2.85 | 70 2.76 | 70 2.76 | 67.5 2.66 | 67.5 2.66 |
| Chainstay Length (I) | 415 16.34 | 415 16.34 | 415 16.34 | 415 16.34 | 415 16.34 | 417 16.42 | 417 16.42 |
| Wheelbase (J) | 969.7 38.18 | 975.6 38.41 | 977.3 38.48 | 984.9 38.78 | 995 39.17 | 1007.9 39.68 | 1027.8 40.46 |
| Frame Reach (K) | 372.9 14.68 | 381.5 15.02 | 383.4 15.09 | 386.9 15.23 | 389.8 15.35 | 390.5 15.37 | 402.8 15.86 |
| Frame Stack (L) | 493.2 19.42 | 494.7 19.48 | 510.7 20.11 | 533.9 21.02 | 557.7 21.96 | 583.8 22.98 | 612.4 24.11 |
| Standover Height (M) | 717.13 28.23 | 729.43 28.72 | 747.69 29.44 | 775.85 30.55 | 801.17 31.54 | 832.25 32.77 | 862.17 33.94 |
