CASCADE: Lightweight & Durable Entry-Level Hardtail
CASCADE 5
Features
-
ALX frame
Lightweight hydroformed ALX frame, manufactured in-house at Polygon's factory.
Specification
-
Frameset
FramesetForkFrame ColorDecal Color
-
Drivetrain
ShifterCrankCassetteRear DerailleurBBChainPedal
-
Cockpit
SaddleSeatpostHandlebarHandlestemHeadset
-
Wheel & Tire
Wheel SetWheel SizeTireRimHubSpokes
-
Brake
Brake LeverBrake CaliperRotor
Geometry & Size
| XS (27.5") | S (27.5") | M (27.5") | L (27.5") | S (29") | M (29") | L (29") | XL (29") | |
|---|---|---|---|---|---|---|---|---|
| Height (cm) | 145-155 | 155-165 | 165-175 | 175-185 | 155-165 | 165-175 | 175-185 | 185-195 |
| Seat Tube Length (A) | 360 14.17 | 390 15.35 | 430 16.93 | 460 18.11 | 390 15.35 | 430 16.93 | 460 18.11 | 491 19.33 |
| Seat Tube Angle (B) | 75 2.95 | 75 2.95 | 75 2.95 | 75 2.95 | 75 2.95 | 75 2.95 | 75 2.95 | 75 2.95 |
| Effective Seat Tube Angle (C) | 75 2.95 | 75 2.95 | 74 2.91 | 75 2.95 | 73 2.87 | 74 2.91 | 75 2.95 | 75 2.95 |
| Head Tube Length (D) | 110 4.33 | 115 4.53 | 120 4.72 | 125 4.92 | 90 3.54 | 95 3.74 | 99 3.9 | 110 4.33 |
| Head Tube Angle (E) | 69 2.72 | 70 2.76 | 68 2.68 | 69 2.72 | 68 2.68 | 69 2.72 | 68 2.68 | 68 2.68 |
| Effective Top Tube (F) | 539 21.22 | 561 22.09 | 581 22.87 | 603 23.74 | 565 22.24 | 585 23.03 | 604 23.78 | 624 24.57 |
| Bb Height (G) | 310 12.2 | 310 12.2 | 309 12.17 | 310 12.2 | 304 11.97 | 303 11.93 | 303 11.93 | 304 11.97 |
| Bb Offset (H) | -45 -1.77 | -45 -1.77 | -45 -1.77 | -45 -1.77 | -69 -2.72 | -69 -2.72 | -69 -2.72 | -69 -2.72 |
| Chainstay Length (I) | 440 17.32 | 440 17.32 | 440 17.32 | 440 17.32 | 455 17.91 | 455 17.91 | 454 17.87 | 455 17.91 |
| Wheelbase (J) | 1085 42.72 | 1108 43.62 | 1129 44.45 | 1151 45.31 | 1122 44.17 | 1142 44.96 | 1161 45.71 | 1182 46.54 |
| Frame Reach (K) | 380 14.96 | 400 15.75 | 420 16.54 | 440 17.32 | 400 15.75 | 420 16.54 | 440 17.32 | 453 17.83 |
| Frame Stack (L) | 596 23.46 | 601 23.66 | 606 23.86 | 610 24.02 | 620 24.41 | 624 24.57 | 629 24.76 | 638 25.12 |
| Standover Height (M) | 646 25.43 | 704 27.72 | 734 28.9 | 756 29.76 | 709 27.91 | 736 28.98 | 759 29.88 | 780 30.71 |
Related Products
The CASCADE is built for the rider who doesn’t want to be limited by the pavement. From city commutes to weekend explorations on forest paths, the CASCADE is built around…
The CASCADE is built for the rider who doesn’t want to be limited by the pavement. From city commutes to weekend explorations on forest paths, the CASCADE is built around…
The CASCADE is built for the rider who doesn’t want to be limited by the pavement. From city commutes to weekend explorations on forest paths, the CASCADE is built around…
The Polygon COLLOSUS N is our ultimate enduro mountain bike. Developed over two seasons by the PFR team on the EDR circuit, we’ve refined every detail and link to ensure…
A full suspension E-MTB, built with our IFS Technology and excellent interface to really take you beyond.
An enduro bike built to charge descents, climb with ease, and proven by the pros.
FAQ
-
Is it already hidraulic discbrake?
Yes it has for a better braking system
-
What is the widest tire I can fit it?
The widest tire that can fit it for optimal riding experience is 2.10”
-
What is the drivetrain of the bike?
The drivetrain came from Shimano Tourney series
-
What is XC Sport Bike
An MTB designed for a light trail riding with an upright position for a leisure experience
-
Where can I ride XC Sport Bike
On a soil or dirt trail along the woods or bike parks with no technical terrain. You can also ride it on tarmac comfortably
-
How long the travel on XC Sport Bike
For it purposes, XC Sport Bikes is designed with 100-120mm fork travel
