Specification
The specifications, colors, parts, and availability of the products can be subjects to alter without prior notification.
-
Frameset
FramesetForkRear Shock
-
Drivetrain
ShifterCrankCassetteRear DerailleurBBChainPedal
-
Cockpit
SaddleSeatpostHandlebarHandlestemHeadset
-
Wheel & Tire
Wheel SetWheel SizeTire
-
Brake
Brake Lever
-
Other
Frame Weight
Geometry & Size
S (27.5″) | M (27.5″) | L (29″) | XL (29″) | |
---|---|---|---|---|
Height (cm) | 152-165 | 162-175 | 172-185 | 182-195 |
Seat Tube Length (A) | 395 15.55 | 435 17.13 | 485 19.09 | 520 20.47 |
Seat Tube Angle (B) | 68.5 2.7 | 68.5 2.7 | 68.5 2.7 | 68.5 2.7 |
Effective Seat Tube Angle (C) | 74.9 2.95 | 74.5 2.93 | 74.1 2.92 | 73.9 2.91 |
Head Tube Length (D) | 105 4.13 | 110 4.33 | 105 4.13 | 110 4.33 |
Head Tube Angle (E) | 66 2.6 | 66 2.6 | 66.5 2.62 | 66.5 2.62 |
Effective Top Tube (F) | 571 22.48 | 596.3 23.48 | 627.4 24.7 | 656.7 25.85 |
Bb Height (G) | 336.5 13.25 | 336.5 13.25 | 337 13.27 | 337 13.27 |
Bb Offset (H) | 20 0.79 | 20 0.79 | 39 1.54 | 39 1.54 |
Chainstay Length (I) | 430 16.93 | 430 16.93 | 435 17.13 | 435 17.13 |
Wheelbase (J) | 1145.9 45.11 | 1168 45.98 | 1192.8 46.96 | 1219.8 48.02 |
Frame Reach (K) | 410 16.14 | 430 16.93 | 450 17.72 | 475 18.7 |
Frame Stack (L) | 595.1 23.43 | 599.7 23.61 | 623 24.53 | 627.6 24.71 |
Standover Height (M) | 663.3 26.11 | 695.1 27.37 | 734.3 28.91 | 758.7 29.87 |
