Charge Up The Trails
COLLOSUS TE 0 AXS
Features
-
Compact and robust IFS linkage design
The main part of the IFS system is the lower twin link at the bottom of the seat tube, on the TE we separated the links which gives us more freedom to keep the same anti squat, which was all dictated by the characteristics of the previous model.
-
A ride that’s balanced, powerful, and light
With a rear end length of 450mm, the Collosus TE delivers a well-balanced ride. The longer chainstays are designed to seamlessly accommodate the Bosch Performance Line CX motor, providing a powerful max 100 Nm of torque paired with a 800 Wh battery. It climbs with ease and descends with the confidence of a full enduro bike.
-
UDH compatibility for next-gen shifting
With the UDH dropouts, the Collosus TE is now compatible with T-Type drivetrains for seamless integration with modern shifting systems.
-
Ready for a more robust dropper post
Now featuring a 34.9mm seat tube diameter to support stronger, more reliable dropper posts.
-
Double-row bearings, consistent performance
The frame runs 3901 double row sealed bearings, ensuring unparalleled consistency across all main pivot points, including the shock yoke.
Specification
-
Frameset
FramesetForkRear ShockSizeFrame ColorDecal Color
-
Drivetrain
ShifterCrankCassetteRear DerailleurChain
-
Cockpit
SaddleSeatpostHandlebarHandlestemHeadset
-
Wheel & Tire
Wheel SetTireRimHubSpokes
-
Brake
Brake LeverBrake CaliperRotor
-
Electric Parts
MotorSensorBattery
Geometry & Size
| S | M | L | XL | |
|---|---|---|---|---|
| Height (cm) | 155-165 | 165-175 | 175-185 | 185-195 |
| Seat Tube Length (A) | 390 15.35 | 400 15.75 | 415 16.34 | 430 16.93 |
| Seat Tube Angle (B) | 72.6 2.86 | 73 2.87 | 73.3 2.89 | 73.5 2.89 |
| Effective Seat Tube Angle (C) | 77 3.03 | 77 3.03 | 75 2.95 | 77 3.03 |
| Head Tube Length (D) | 90 3.54 | 100 3.94 | 115 4.53 | 130 5.12 |
| Head Tube Angle (E) | 62.5 2.46 | 64.5 2.54 | 64.5 2.54 | 64.5 2.54 |
| Effective Top Tube (F) | 568.8 22.39 | 610.5 24.04 | 630.1 24.81 | 652.5 25.69 |
| Bb Height (G) | 340 13.39 | 340 13.39 | 340 13.39 | 340 13.39 |
| Bb Offset (H) | 38 1.5 | 38 1.5 | 38 1.5 | 38 1.5 |
| Chainstay Length (I) | 450 17.72 | 449 17.68 | 450 17.72 | 450 17.72 |
| Wheelbase (J) | 1216 47.87 | 1245 49.02 | 1272 50.08 | 1298 51.1 |
| Frame Reach (K) | 440 17.32 | 465 18.31 | 485 19.09 | 505 19.88 |
| Frame Stack (L) | 620 24.41 | 629 24.76 | 643 25.31 | 656 25.83 |
| Standover Height (M) | 738 29.06 | 733 28.86 | 727 28.62 | 722 28.43 |
Related Products
An e-trail machine built to dominate climbs, crush descents, and go big.
A lightweight carbon e-trail bike designed to conquer climbs, charge down descents, and push the limits of every ride.
A lightweight carbon e-trail bike designed to conquer climbs, charge down descents, and push the limits of every ride.
A full suspension E-MTB, built with our IFS Technology and excellent interface to really take you beyond.
Comes from the bloodline of a champion Collosus N, we give you another perspective to have more fun and tame the trails with the combination of our proven suspension platform;…
An SUV e-bike designed for optimal mobility comfort and reliability on various types of terrain, a perfect weapon for both on urban roads and off-road
An SUV e-bike designed for optimal mobility comfort and reliability on various types of terrain, a perfect weapon for both on urban roads and off-road
An SUV e-bike designed for optimal mobility comfort and reliability on various types of terrain, a perfect weapon for both on urban roads and off-road
FAQ
-
That doesn’t look like the IFS system, how is it the same as the Collosus N’s?
The main part of the IFS system is the double link at the bottom of the seat tube. On the Collosus TE we separated the links which gives us more freedom to keep the same anti squat, which was all dictated by the characteristics of the previous model.
-
Is the bike compatible with a coil shock?
No. The frame does not have the clearance to fit a coil shock—it is designed specifically for the air shock supplied with the bike.
-
What is the maximum tyre?
Max tire is 2.6”
-
Can the bike be setup as a mullet
No
-
UDH derailleur hanger compatible?
Yes, the frames use UDH
-
Why are the Chainstay all the same length?
The chainstays are the same length between all sizes because we had to allow room for the BOSCH Motor
-
How do I charge the battery? And how long will it take?
The battery can be charged either installed in the bike, via the charging port on the left side in front of the motor, or detached from the bike using the additional connection port supplied with the charger. Charging to 50% takes approximately 2 hours, while a full charge requires 4 hours.
A special note for Indonesia: please use a 220-240V charger, not a 110V charger, to avoid any potential issues. -
I like to ride in mud, are the electronics weather-proof?
Yes. The BOSCH Performance Line CX systems are waterproof for use under normal riding conditions. Please do not use a high-pressure washer to clean your bike.
-
How fast can I ride?
When gravity is on your side, there is no limiting your speed beyond that of a “normal” MTB with 160mm of awesome suspension. As far as motor assistance is concerned, the BOSCH Performance Line CX systems will provide motor assistance up to 20mph (32km/h) in the USA and Indonesia, or 25km/h in Europe and Australia.
-
How far can I ride?
Range varies based on terrain, elevation, rider weight, assist mode, pedaling effort, temperature, and more. In optimal conditions, rides up to 190 km are possible in ECO+ mode. For the most accurate estimate during your ride, check the Range overview on the display.
The Collosus TE offers four assist modes—ECO+, Tour+, eMTB, and eMTB+. For the best efficiency, match your gears to the terrain and save higher assist levels for climbs. -
What is the weight of the Collosus TE?
Size M = 23.8 kg
(*) Applies to both Collosus TE0 and Collosus TE8 models. -
What are the differences between Collosus TLE and Collosus TE?
Each model serves a different purpose—TLE is for a more analog feeling, trail-oriented feel; TE for a longer, more demanding ride—reflected in their distinct specs, like battery size and torque.
