SEIZE THE JOURNEY
SYNCLINE C3
Comes with a slack head tube angle and short chainstay, Syncline C takes you to have an excellent acceleration and the best performance on switchback turns. Along with the reliable hydraulic disc brakes, you are in control.
There’s more in less. The biggest advantage from a 1x drivetrain is it lets you to focus on your ride, instead of constantly adjusting gears. Now you can have more and better experience on trails.
Built with adaptive carbon frame, Synline C gives you a better pedaling efficiency and riding feel. The journey is yours.
Less flex for excellent front-end control with its tapered head tube design
Spesifikasi
*Spesifikasi, warna dan ketersediaan produk dapat berubah sewaktu-waktu tanpa pemberitahuan sebelumnya.
-
Frameset
FramesetForkRear Shock
-
Drivetrain
ShifterCrankCassetteRear DerailleurBBChainPedal
-
Cockpit
SaddleSeatpostHandlebarHandlestemHeadset
-
Wheel & Tire
Wheel SetWheel SizeTireRimHub
-
Brake
Brake LeverBrake CaliperRotor
Geometry & Size
| S (27.5”) | M (27.5”) | M (29”) | L (29”) | XL (29”) | |
|---|---|---|---|---|---|
| Tinggi Badan (cmfeet) | 155-165 5'1"-5'5" | 165-175 5'5"-5'9" | 165-175 5'5"-5'9" | 175-185 5'9"-6'1" | 185-195 6'1"-6'5" |
| Seat Tube Length (A) | 380 14.96 | 420 16.54 | 420 16.54 | 460 18.11 | 500 19.69 |
| Seat Tube Angle (B) | 73 2.87 | 73 2.87 | 73 2.87 | 73 2.87 | 73 2.87 |
| Effective Seat Tube Angle (C) | 75.3 2.96 | 75.3 2.96 | 75.3 2.96 | 75.3 2.96 | 75.3 2.96 |
| Head Tube Length (D) | 100 3.94 | 120 4.72 | 100 3.94 | 120 4.72 | 140 5.51 |
| Head Tube Angle (E) | 67 2.64 | 67 2.64 | 67 2.64 | 67 2.64 | 67 2.64 |
| Effective Top Tube (F) | 569 22.4 | 594.6 23.41 | 597.7 23.53 | 621 24.45 | 649.15 25.56 |
| Bb Height (G) | 308.5 12.15 | 308.5 12.15 | 307.5 12.11 | 307.5 12.11 | 307.5 12.11 |
| Bb Offset (H) | 45 1.77 | 45 1.77 | 64 2.52 | 65 2.56 | 65 2.56 |
| Chainstay Length (I) | 425 16.73 | 425 16.73 | 435 17.13 | 435 17.13 | 435 17.13 |
| Wheelbase (J) | 1106.94 43.58 | 1134.8 44.68 | 1149.5 45.26 | 1176.9 46.33 | 1204.76 47.43 |
| Frame Reach (K) | 410 16.14 | 430 16.93 | 430 16.93 | 450 17.72 | 470 18.5 |
| Frame Stack (L) | 596.6 23.49 | 615 24.21 | 633.2 24.93 | 651.6 25.65 | 670 26.38 |
| Standover Height (M) | 690.9 27.2 | 729.2 28.71 | 730.8 28.77 | 763.7 30.07 | 779.2 30.68 |
Related Products
Big thanks to modern geometry; a slacker head angle and longer reach and steeper seat, makes the Polygon Siskiu D series unbelievably capable for riders looking to tackle XC riding…
Big thanks to modern geometry; a slacker head angle and longer reach and steeper seat, makes the Polygon Siskiu D series series unbelievably capable for riders looking to tackle XC…
FAQ
-
Apa model drivetrain Polygon Syncline C3?
Polygon Syncline C3 dilengkapi dengan drivetrain dari Shimano Deore
-
Apakah aman menambah travel fork sepedanya?
120mm travel adalah spesifikasi optimal sepeda tersebut dan menambah travel dapat membuat frame menjadi stress
-
Apakah bisa bannya diganti menjadi yang lebih lebar?
Ban yang lebih lebar dapat bergesekan dengan fork, rantai, dan segitiga belakang sehingga kami tidak merekomendasikannya
-
Apa itu sepeda XC Trail
Sepeda yang didesain untuk medan pegunungan yang lebih menanjak namunt tetap nyaman dikendarai. Dapat dijumpai dalam model hardtail maupun full suspension
-
Dimana saya bisa mengendarainya?
Anda dapat mengendarainya pada jalur-jalur bike park lokal maupun trek pegunungan
-
Berapa panjang travel fork sepeda XC Trail?
Secara umum didesain dengan 120mm fork travel
