Downhill Demolition
COLLOSUS DH7
Features
-
Multiple setup possibilities
The Collosus DH offers 4 geometry configurations using two flip-chips. Riders can fine-tune the bottom bracket position for either a mullet setup with a 27.5” rear wheel or a full 29er configuration. When using a smaller rear wheel, set the flip chip in its tallest position to maintain rear center height. Switching to a 29” rear wheel allows the frame to drop down, ensuring a consistent riding position across wheel sizes.
-
Dial In Your Perfect Geometry
With a 1.5” headset, riders can further customize their ride by fitting aftermarket angle-adjust cups, dialing in the perfect geometry for their style and terrain.
-
No Compromise
Our innovative 6-bar independent floating suspension is engineered to control wheel path and anti-squat independently to the leverage curve, ensuring optimal performance across varied terrain.
-
UDH Compatibility for Next-Gen Shifting
With the UDH dropouts, the Collosus DH is now compatible with T-Type drivetrains for seamless integration with modern shifting systems.
Specification
-
Frameset
FramesetForkRear ShockFrame ColorDecal Color
-
Drivetrain
ShifterCrankCassetteRear DerailleurBBChainPedal
-
Cockpit
SaddleSeatpostHandlebarHandlestemHeadset
-
Wheel & Tire
Wheel SetWheel SizeTireRimHubSpokes
-
Brake
Brake LeverBrake CaliperRotor
Geometry & Size
| S | M | L | XL | |
|---|---|---|---|---|
| Height (cm) | 155-165 | 165-175 | 175-185 | 185-195 |
| Seat Tube Length (A) | 390 15.35 | 390 15.35 | 390 15.35 | 390 15.35 |
| Seat Tube Angle (B) | 72 2.83 | 72 2.83 | 72 2.83 | 72 2.83 |
| Effective Seat Tube Angle (C) | 78.5 3.09 | 78.5 3.09 | 78.5 3.09 | 78.5 3.09 |
| Head Tube Length (D) | 105 4.13 | 105 4.13 | 105 4.13 | 105 4.13 |
| Head Tube Angle (E) | 63 2.48 | 63 2.48 | 63 2.48 | 63 2.48 |
| Effective Top Tube (F) | 557 21.93 | 580 22.83 | 600 23.62 | 622 24.49 |
| Bb Height (G) | 356 14.02 | 356 14.02 | 356 14.02 | 356 14.02 |
| Bb Offset (H) | 24 0.94 | 24 0.94 | 24 0.94 | 24 0.94 |
| Chainstay Length (I) | 445 17.52 | 445 17.52 | 445 17.52 | 445 17.52 |
| Wheelbase (J) | 1250 49.21 | 1273 50.12 | 1293 50.91 | 1315 51.77 |
| Frame Reach (K) | 437 17.2 | 460 18.11 | 480 18.9 | 502 19.76 |
| Frame Stack (L) | 632 24.88 | 632 24.88 | 632 24.88 | 632 24.88 |
| Standover Height (M) | 817 32.17 | 817 32.17 | 817 32.17 | 817 32.17 |
| S | M | L | XL | |
|---|---|---|---|---|
| Height (cm) | 155-165 | 165-175 | 175-185 | 185-195 |
| Seat Tube Length (A) | 390 15.35 | 390 15.35 | 390 15.35 | 390 15.35 |
| Seat Tube Angle (B) | 71.6 2.82 | 71.6 2.82 | 71.6 2.82 | 71.6 2.82 |
| Effective Seat Tube Angle (C) | 78.1 3.07 | 78.1 3.07 | 78.1 3.07 | 78.1 3.07 |
| Head Tube Length (D) | 105 4.13 | 105 4.13 | 105 4.13 | 105 4.13 |
| Head Tube Angle (E) | 62.6 2.46 | 62.6 2.46 | 62.6 2.46 | 62.6 2.46 |
| Effective Top Tube (F) | 558 21.97 | 581 22.87 | 601 23.66 | 623 24.53 |
| Bb Height (G) | 350 13.78 | 350 13.78 | 350 13.78 | 350 13.78 |
| Bb Offset (H) | 30 1.18 | 30 1.18 | 30 1.18 | 30 1.18 |
| Chainstay Length (I) | 446 17.56 | 446 17.56 | 446 17.56 | 446 17.56 |
| Wheelbase (J) | 1251 49.25 | 1274 50.16 | 1294 50.94 | 1316 51.81 |
| Frame Reach (K) | 433 17.05 | 456 17.95 | 476 18.74 | 498 19.61 |
| Frame Stack (L) | 635 25 | 635 25 | 635 25 | 636 25.04 |
| Standover Height (M) | 813 32.01 | 813 32.01 | 813 32.01 | 813 32.01 |
Related Products
A precision-engineered machine built for speed, control, and domination on the gnarliest descents
Our all-time sorcerer — Cascade 2, born for you who are planning to go for recreational riding on the weekends and feel the mountains. The Cascade 2 MTB is built…
Our all-time sorcerer — Cascade, born for you who are planning to go for recreational riding on the weekends and feel mountains. The Cascade MTB is built with a lightweight…
Created to be versatile bikes for riders who are looking for a bike to commute to work during the weekdays.
Our all-time sorcerer — Cascade 4, born for you who are planning to go for recreational riding on the weekends and feel the mountains. The Cascade 4 MTB is built…
Created to be versatile bikes for riders who are looking for a bike to commute to work during the weekdays.
FAQ
-
Can both wheels be 27.5", or is the bike limited to mullet and full 29” setups?
The Collosus DH is designed for mullet (MX) or full 29” setups. A full 27.5” setup is not supported.
-
Is the bike compatible with a single crown fork?
Yes, if you use a 190mm travel fork.
-
Can I install a dropper post on this bike?
No, the bike is not designed to accommodate a dropper post.
-
What are the axle sizes?
Rear axle: 12 x 157mm DH (OLD).
-
Is the frame UDH-compatible?
Yes, the Collosus DH uses a UDH derailleur hanger, making it compatible with modern drivetrain systems.
-
What is the shock size and eye-to-eye measurement?
Shock size: 250mm x 75mm.
-
What type of rear suspension travel does the bike have?
The suspension system follows a progressive travel curve.
-
Can I use a coil shock on this bike?
Yes, the frame is compatible with all aftermarket coil shocks.
-
Do chainstay lengths vary by frame size?
No, the chainstay length is 445mm across all sizes.
-
What is the head tube size?
The bike features a 1.5” headset, allowing for further geometry adjustments with angle-adjust cups.
