Charge Up The Trails

Unmatched performance in an SL e-trail bike

We’re proud to unveil the latest evolution in our lineup: the Collosus TLE. Born from a passion to push the limits of our Collosus platform, the TLE was designed to elevate the trail experience for riders like you. Drawing inspiration from the success of the Collosus N and DH models, the TLE reintroduces carbon construction and integrates our Independent Floating Suspension (IFS) system—refined to be lighter, stiffer, and more efficient than ever. The goal? Deliver unmatched performance without compromise. Years of development and rider feedback shaped the Collosus TLE into more than just a bike; it’s a companion built for progress. With a custom-tuned ride feel and dialed-in suspension kinematics, it balances anti-squat, anti-rise, and leverage curve to deliver precise climbing efficiency, confident braking, and plush responsiveness on every descent. Built around a full 29er platform, the TLE features Fox-tuned shocks and a versatile shock yoke, offering extensive adjustability to match your style. Practical touches like tailgate protection, generous chainstay coverage, and internal cable routing complete a clean, quiet ride on any trail. The TLE is also future-ready, with Bosch motor compatibility, a range extender option, and a Bosch PowerMore 250Wh battery included as standard—ready to take on long rides and epic adventures alike. The Collosus TLE is more than a new model—it’s a statement of our commitment to progress, performance, and the journey ahead. Experience what’s next in full-suspension carbon trail bikes.

COLLOSUS TLE 8 AXS

Color

Size

Clear

Find my size

FIND DEALER

SKU : 503258

Specification

Frameset

Frameset

ACX e-MTB

Fork

MARZOCCHI BOMBER Z1, 160mm TRAVEL, OFFSET: 44mm, AIR SPRING, RAIL DAMPER,REBOUND ADJUST

Rear Shock

MARZOCCHI BOMBER AIR, E2E: 210x55mm

Frame Color

BLACK / BRONZE

Decal Color

BLACK SILVER
Drivetrain

Shifter

SRAM EC AXS POD CONTROLLER, 1x12-SPEED TRIGGER

Crank

SRAM CR T-TYPE, 34T

Cassette

SRAM GX EAGLE T-TYPE 10-52T XD DRIVER

Rear Derailleur

SRAM GX EAGLE T-TYPE AXS

Chain

SRAM GX EAGLE T-TYPE
Cockpit

Saddle

XTENT, CR-MO ø7mm

Seatpost

TRANZ X JD-YSP39KL 170mm (S, M) / 200mm (L, XL) TRAVEL, DxL: 34.9 x 495mm (S, M) / 556mm (L, XL)

Handlebar

POLYGON EXPERT, W: 780mm, BB: 35mm, R/D: 30mm, B: 9degree

Handlestem

POLYGON EXPERT, EXT: 35mm, BB: 35mm, R/D: 0mm

Headset

FSA NO.42/47/ACB, IS 42/28.6 | IS 52/40
Wheel & Tire

Wheel Set

MT6 TUBELESS READY

Wheel Size

29"

Tire

MAXXIS DISSECTOR 29"x2.40" 622x65, TLE

Rim

F: ALLOY DOUBLE WALL FV H:18mm 622x36 32H FOR TYRE 622-54/76 W/ TUBELESS TAPE / R: ALLOY DOUBLE WALL FV H:18mm 622x36 32H FOR TYRE 622-54/76 W/ TUBELESS TAPE

Hub

F: DT SWISS 370 HYBRID CLASSIC 15x110mm 32H 6-BOLT / R: DT SWISS 370 HYBRID CLASSIC 12x148mm 32H 6-BOLT FOR XD DRIVER

Spokes

F: STAINLESS 14G NDS:292mm DS:294mm W/ 12mm BRASS NIPPLE / R: STAINLESS 14G NDS:294mm DS:292mm W/ 12mm BRASS NIPPLE
Brake

Brake Lever

MAGURA HC3

Brake Caliper

MAGURA MT7 HYDRAULIC DISC

Rotor

MAGURA MDR C, 203MM 6-BOLT
Electric Parts

Motor

BOSCH PERFORMANCE LINE SX BDU3145

Sensor

BOSCH RIM MAGNET

Battery

BOSCH COMPACTTUBE 400 FIXED MOUNT HORIZONTAL

Geometry & Size

mm inch

Find your size

	S	M	L	XL
Height (cm)	155-165	165-175	175-185	185-195
Seat Tube Length (A)	390 15.35	400 15.75	415 16.34	430 16.93
Seat Tube Angle (B)	72.2 2.84	72.6 2.86	72.9 2.87	73.1 2.88
Effective Seat Tube Angle (C)	76.6 3.02	76.6 3.02	76.6 3.02	76.6 3.02
Head Tube Length (D)	90 3.54	95 3.74	105 4.13	120 4.72
Head Tube Angle (E)	64.1 2.52	64.1 2.52	64.1 2.52	64.1 2.52
Effective Top Tube (F)	586 23.07	607 23.9	627 24.69	648 25.51
Bb Height (G)	343 13.5	343 13.5	343 13.5	343 13.5
Bb Offset (H)	35 1.38	35 1.38	35 1.38	35 1.38
Chainstay Length (I)	450 17.72	450 17.72	450 17.72	450 17.72
Wheelbase (J)	1215 47.83	1242 48.9	1266 49.84	1293 50.91
Frame Reach (K)	435 17.13	461 18.15	481 18.94	501 19.72
Frame Stack (L)	614 24.17	619 24.37	628 24.72	642 25.28
Standover Height (M)	748 29.45	757 29.8	764 30.08	770 30.31

FAQ

That doesn’t look like the IFS system, how is it the same as the N9?

The main part of the IFS system is the double link at the bottom of the seat tube, on the Collosus TLE we separated the links which gives us more freedom to keep the same anti squat, which was all dictated by the characteristics of the previous model.
Is the bike compatible with a coil shock?

Yes, the Collosus TLE is compatible with a coil shock. It comes stock with 140mm rear travel paired with a Fox Float X air shock (R model) and a 160mm Fox fork up front, matched with a confidence-inspiring 64° head angle. You can also “over-fork” it by 10mm to bump the fork travel up to 170mm if desired. Shock hardware sizes are 25mm x 8mm (front) and 15mm x 8mm (rear yoke).
What is the maximum tyre?

Max tire is 2.6”.
Can the bike be setup as a mullet?

No.
UDH derailleur hanger compatible?

Yes, the frames use UDH.
Can the bike fit a coil?

Yes, you can fit a coil shock.
What is the Dropper Post Insertion?

It can fit a 200mm dropper in the Medium RAD brand - insertion will change depending on the size.
Why are the Chainstay all the same length?

The chainstays are the same length because we had to allow room for the Bosch Motor.
How do I charge the battery? And how long will it take?

The battery can be charged either installed in the bike, via the charging port on the left side in front of the motor, or detached from the bike using the additional connection port supplied with the charger. Charging to 50% takes. approximately 2 hours, while a full charge requires 4 hours.

A special note for Indonesia: please use a 220-240V charger, not a 110V charger, to avoid any potential issues.
I like to ride in mud, are the electronics weather-proof?

Yes. The BOSCH Performance Line SX systems are waterproof for use under normal riding conditions. Please do not use a high-pressure washer to clean your bike.
How fast can I ride?

When gravity is on your side, there is no limiting your speed beyond that of a “normal” MTB with 150mm of awesome suspension. As far as motor assistance is concerned, the BOSCH Performance Line SX systems will provide motor assistance up to 20mph (32km/h) in the USA and Indonesia, or 25km/h in Europe and Australia.
How far can I ride?

The range of any e-MTB depends on many variables, including terrain, gradients, rider weight, assistance mode, rider input, ambient temperature, etc. While 125 km adventures* are definitely achievable aboard the Collosus TLE, we recommend using the Range overview on the display for the best estimate. The range overview is recalculated continuously by calculating speed, rider behavior and power consumption. This means that range overview makes a prediction, which can vary depending on these different factors.

(*) With ECO mode
What is the weight of the Collosus TLE?

Size M = 22.2 kg

(*) Applies to both Collosus TLE0 and Collosus TLE8 models.
