COLLOSUS TE6 2027
-
503482
-
E-MTB ?E-MTB ?Whether it's climbing and going down steep trails or jumping high at bike parks. Enjoy your riding and discover yourself. See more...
Crafted for big missions and aggressive riders, the 2026 Collosus TE8 electric MTB is Polygon's new e-trail machine. It's built with a full carbon frame, and both the front and rear triangles are designed to be agile, responsive, and ready for anything.The Collosus TE8 electric MTB features the proven compact model of the IFS (Independent Floating Suspension) system, used on the Collosus N and DH series. This system delivers exceptional small-bump sensitivity and strong mid-stroke support, pairing perfectly with air shocks for a confident and balanced ride.The 29er-wheel setup provides a playful yet planted feel. The quiet and natural-feeling BOSCH Performance Line CX motor, with 100 Nm of torque and an 800 Wh battery, brings effortless power to every climb and sprint.An extended chainstay enhances rear-wheel traction, and the UDH-compatible hanger supports modern drivetrains. The low standover height keeps your center of gravity low and lets you charge harder and ride sharper, no matter what the trail throws your way.
Specification
-
Frameset
FramesetForkRear ShockSizeFrame ColorDecal Color
-
Drivetrain
ShifterCrankCassetteRear DerailleurChain
-
Cockpit
SaddleSeatpostHandlebarHandlestemHeadset
-
Wheel & Tire
Wheel SetTireRimHubSpokes
-
Brake
Brake LeverBrake CaliperRotor
-
Electric Parts
MotorSensorBattery
Geometry & Size
| S | M | L | XL | |
|---|---|---|---|---|
| Height (cm) | 155-165 | 165-175 | 175-185 | 185-195 |
| Seat Tube Length (A) | 390 15.35 | 400 15.75 | 415 16.34 | 430 16.93 |
| Seat Tube Angle (B) | 72.6 2.86 | 73 2.87 | 73.3 2.89 | 73.5 2.89 |
| Effective Seat Tube Angle (C) | 77 3.03 | 77 3.03 | 77 3.03 | 77 3.03 |
| Head Tube Length (D) | 90 3.54 | 100 3.94 | 115 4.53 | 130 5.12 |
| Head Tube Angle (E) | 64.5 2.54 | 64.5 2.54 | 64.5 2.54 | 64.5 2.54 |
| Effective Top Tube (F) | 568.8 22.39 | 610.5 24.04 | 630.1 24.81 | 652.5 25.69 |
| Bb Height (G) | 339 13.35 | 340 13.39 | 340 13.39 | 340 13.39 |
| Bb Offset (H) | 38 1.5 | 38 1.5 | 38 1.5 | 38 1.5 |
| Chainstay Length (I) | 450 17.72 | 450 17.72 | 450 17.72 | 450 17.72 |
| Wheelbase (J) | 1216 47.87 | 1245 49.02 | 1272 50.08 | 1298 51.1 |
| Frame Reach (K) | 440 17.32 | 465 18.31 | 485 19.09 | 505 19.88 |
| Frame Stack (L) | 620 24.41 | 629 24.76 | 643 25.31 | 656 25.83 |
| Standover Height (M) | 738 29.06 | 733 28.86 | 727 28.62 | 722 28.43 |
