The frame has clearance for a 27.5x2.8" tire so a mullet (29” front, 27.5+ rear) is possible. However, the diameter of a 27.5x2.8" tire is significantly smaller than the standard 29x2.6" tire, hence changing to a mullet set up would reduce BB height and pedal to ground clearance while also slackening both the effective seat and head tube angles.The fork will also fit a 27.5+ tire, however, this is highly discouraged as the BB drop would become dangerously low. We recommend staying ready for business with 29" all-round.

Most 205mm x 65mm Trunnion Mount shocks should fit. The leverage curve can work well with a coil shock. However, it’s worth noting that Polygon have Fox tune the stock rear shocks to work best with the specific bike model, so a standard tune replacement shock may not offer optimized performance.

You’ll need to use an e-MTB rated fork to ensure it is strong enough to withstand the additional forces and punishment that can be encountered by e-MTBs. The standard forks are 160mm travel, but you can run up to 170mm travel if you like. You cannot use a dual crown fork as the frame is not designed or tested to withstand the different loads.

For sure, the bike comes equipped with an e*thirteen E*Spec Plus top guide. The chain guide mounts directly to the drive unit and the bolt pattern is different to traditional ISCG/05, so most ‘normal’ chain guides are not compatible.

You can run up to 220mm rotors front and rear. While you can downsize from the standard 203mm to 180mm, we suggest not to.

Shimano STEPS e-MTB drive systems provide 4 power modes; Eco, Trail, Boost and Walk-Assist; and its E-TUBE PROJECT app lets you customize the assistance of each mode to your personal preferences.We recommend only shifting one gear at a time (up or down the cassette) and try to back off the power through the cranks a little as the integrated torque sensor will immediately react and also back off the motor’s power. Trail mode is much more intuitive with this than Boost mode. We recommend saving Boost mode for cranking straight-up big climbs where gear shifting is limited.

Insert a 4mm Allen key into the hole above the battery cover on the underside of the downtube. Rotate it in the direction depicted by the arrow to release the battery lock. This will allow the battery to hang slightly down from the tube, creating access to the battery release lever at the top of the battery. Be sure to use two hands when releasing the battery as it’s quite heavy and shouldn’t be dropped.

Ensure the battery connections are clean and dry. Install the base of the battery into the lower mount closest to the motor, then press the top of the battery into the downtube until you hear and feel a “click”. Then your battery is installed.

The battery can be charged either installed in the bike, via the charging port on the left side in front of the motor, or detached from the bike using the additional connection port supplied with the charger.

Yes. The SHIMANO STEPS systems are waterproof for use under normal riding conditions, including heavy rain. Please do not use a high pressure washer to clean your bike.

When gravity is on your side, there is no limiting your speed beyond that of a “normal” MTB with 160mm of awesome suspension. As far as motor assistance is concerned, the Shimano STEPS systems will provide motor assistance up to 20mph (32km/h) in the USA and Indonesia, or 25km/h in Europe and Australia.

The range of any e-MTB depends on many variables, including terrain, gradients, rider weight, assistance mode, rider input, ambient temperature, etc. While 100km adventures are definitely achievable aboard the Collosus N8e, we recommend using the range overview on the display for the best estimate. The range overview is recalculated continuously by calculating speed, rider behavior, and power consumption. This means that range overview makes a prediction, which can vary depending on these different factors.

The electricity components equipped on E-bike, click here for more details.

Stay tuned on our website and social media, we will announce further for the availability.

No, the Collosus N8E was designed around Shimano’s BT-EN806 630Wh battery as it helps Collosus hit the sweet spot of lighter weight for agility, attainable price points while still offering enough capacity for very big rides.

Yes. Shimano approved front lights can be connected to ports in the STEPS drive unit (motor). This requires significant internal routing and e-system component removal so we recommend having this upgrade made by a certified Shimano STEPS workshop.
