SYNCLINE C
An adrenaline machine to ride on more trails
Features
-
Explosive Acceleration
Aggressive geometry with a slack head tube angle and short chainstay for quick acceleration and nimble handling on tight trails.
-
Efficient and Simple Shifting
The 1x drivetrain provides a cleaner, more efficient ride with less maintenance.
-
Responsive Carbon Frame
Offers excellent pedaling efficiency and a direct connection with the trail for enhanced control.
-
Precision Handling
Tapered head tube design ensures precise steering and confidence on challenging descents.
Choose your series
Build Specs
| Kit |
SYNCLINE C5
|
SYNCLINE C3
|
SYNCLINE C2
|
|---|---|---|---|
| Frame | ACX XC PERFORMANCE | ACX XC PERFORMANCE | ACX XC PERFORMANCE |
| Fork | FOX 32 RHYTHM, 120mm | ROCKSHOX RECON SILVER RL, 120mm | SUNTOUR XCR 32 LO-R, 120mm TRAVEL |
| Shifter | SHIMANO SLX SL-M7100-R 12-SPEED TRIGGER | SHIMANO DEORE SL-M6100-R 12-SPEED TRIGGER | SHIMANO DEORE SL-M5100, 1x11 SPEED |
| Crank Set | SHIMANO SLX FC-M7100-1 32T 2-PIECE-CRANK | SHIMANO FC-MT510-1 32T 2-PIECE-CRANK | SHIMANO DEORE FC-M5100 32T |
| Cassette | 12 SPEED 11-51T | 12 SPEED 11-51T | 12 SPEED 11-51T |
| Rear Derailleur | SHIMANO SLX RD-M7100-SGS DIRECT ATTACH | SHIMANO DEORE RD-M6100-SGS DIRECT ATTACH | SHIMANO DEORE RD-M5100 |
| Wheel Set | ALLOY DOUBLE WALL | ALLOY DOUBLE WALL | ALLOY DOUBLE WALL 32H |
| Tire | WTB TRAIL BOSS TIRE, 27.5x2.25 / 29x2.25 | WTB TRAIL BOSS TIRE, 27.5x2.25 / 29x2.25 | WTB TRAIL BOSS 27.5"x2.25" / 29"x2.25" |
| Brake Lever | SHIMANO MT400 HYDRAULIC DISC BRAKE | SHIMANO BL-MT201 | SHIMANO MT200 HYDRAULIC DISC BRAKE |
| Brake Caliper | SHIMANO MT400 HYDRAULIC DISC BRAKE | SHIMANO BR-MT201 | SHIMANO MT200 HYDRAULIC DISC BRAKE |
| Rotor | FRONT:180mm REAR:160mm CENTER-LOCK | SHIMANO SM-RT10 F:180mm R:160MM CENTERL LOCK | FRONT:180mm REAR:160mm CENTER-LOCK |
FAQ
-
What is it made of?
Based on carbon material with ACX technology for a light, responsive yet stiff frame
-
What type of FD suitable for the bike
E-type front pull FD might suits it well
-
Is it safe to add more travel to the bike?
120mm is the peak specification of the bike, adding more will put the frame on a stress
-
What is XC Trail Bike
Bicycle that is designed for more hill climbing and decline yet still comfortably ridden across the country. It can be found on both hardtail and full suspension configuration
-
Where can I ride XC Trail Bike
As it names implies, the bike could conquer local single track to mountainous range
-
How long the travel on XC Trail Bike
You can find the bike with mostly 120mm travel fork
